Crafted by the same experts and handcrafted by the same masters who developed the Vanquish Pro series, this cost-effective choice provides a comparable aerodynamic rim profile and competitive advantage as our professional line without breaking the bank. Achieving high speeds is a matter of minimizing drag and maintaining control. Prepare to make an impression during your next group ride. Looking for an 84mm or Full Aero Disc? Choose the Pro option.
KEY FEATURES
Handmade in the USA
Rim depth options of 45mm and 62mm
22.4mm Internal Width, 30.9mm External Width Rims
HED GP Performance Centerlock Disc Brake Hubs
Tubeless Compatible
Vanquish 45 Overview
Intended Use: Road Race/All-Roa
Tubeless Compatible
Inner rim width: 22.4mm
Optimal Tire Size: 28c
Rim Specs
Rim Weight 453g ± 60.4g
Internal Width: 22.4mm
External Width: 30.9mm
Depth: 45mm
Hole Count: 24
ERD (Includes Washers): 555
Wheelset Build:
Hubs: Front Hub: 12x100mm axle. Centerlock Bearing: EZO Japan 6902RS x 2 Rear Hub: 12x142mm axle. Centerlock. Freehub: 4 pawl: 13 degree engagement. Bearing: EZO Japan 6902RS x 4
Spokes: Sapim Sprint, hooked
Wheelset Weights
Front: 757 Grams
Rear: 896 Grams
Wheelset:1653 Grams
